PEF21-6S

  • Control distance:up to 100m
  • Certificate: CE, FCC ISO9001：2008
  • Operation frequency:310-331Mhz or 425-446Mhz
  • Buttons:6 single speed
  • Relays:6 Relays control functions,1 relay control EMS and 1 relay reserve
  • Working temperature:-35℃~+80℃
  • Material:Glass-fiber nylon-6

Introduction

Description
  • 8 push buttons with 7 single-speed buttons and 1 stop buttons
  • Control points up to 6
  • With the battery voltage alarm device to cut off the circuit when voltage is insufficient.
  • For emergency circumstances, you can take out the magnetic key to cut down the power on a moment.
  • Set the internal functions by computer interface
  • Up/down, east/west, south/ north push button can be set interlock or not.
  • Spare 1 key can be set start, speed up, jump strokes, ordinary etc.
    • Model Operation Button Button Type Transmitter Receiver
    Emergency Stop
    PEF21-6S 6 Single Speed Magnetic Key Push Button
    Transmitter
    Open Keys    		 Receiver EMS Receiver Control Points Receiver
    interface
    Start Yes 6 Cable
